| 5000-pixel array for maximum accuracy |
|
|
| Single or dual camera capability |
|
|
| Measures width, thickness, and taper of drawn and flowing materials or webs. |
|
|
| Detects holes and irregular edges or profiles |
|
|
| Monitors edge displacement, tracking or eccentricity |
|
|
| Gauges gaps and measure width of openings |
|
|
|
|
|
|
A rugged, low cost, non-contact position and dimension monitor that is easy to use
for manufacturing and process control operations. |
|
|
| Easy to use |
| Self-contained unit is ready to operate. High-brightness LED display is easy to read under
normal room lighting even from a distance. The internal keypad allows versatile programming of the
many parameters and the three alarm outputs allowing maximum flexibility of interface. Video and
Sync outputs signals for oscilloscope readout are standard. |
|
|
| Precise and repeatable |
| Resolution and linearity are determined by fixed
spacing of diodes in the 5000 element linear CCD array. Resolution to 1/5000
of full-scale range is achievable through optimization of optics. For example;
full scale range of 1.000" gives a resolution of .0002" |
|
|
| Non-Contact |
Measure moving objects without creating friction,
mechanical loading or distortion. Measure objects in hostile environments such as hot,
cold, vacuum, high voltage, etc. without contact or contaminating the object.
Product Summary PDF |
|
|
|
